Muab ob npaug rau-Pole Miniature Circuit Breaker
Txhim khu kev tiv thaiv Circuit Court rau cov chaw nyob, kev lag luam thiab teeb pom kev lag luam
Peb Ob Chav -Pole Miniature Circuit Breakers (2P MCBs) muab kev sib cais ntawm ob lub conductors, tiv thaiv circuits tiv thaiv overloads thiab luv circuits. Tsim los rau tus qauv DIN-rail mounting nyob rau hauv modular faib boards, cov khoom no yog tsim rau wholesalers, hluav taws xob distributors, vaj huam sib luag tsim, thiab OEM cov neeg muas zaub xav tau ib tug zoo batch zoo thiab txhim khu kev qha kev ua tau zoo.
Ntsiab Technical Specifications
|
Parameter |
Specification |
|
Ncej Configuration |
2P (ib txhij sib txuas ntawm ob tus ncej) |
|
Hom kev tiv thaiv |
Thermal-magnetic (Overload + luv Circuit Court) |
|
Rated Tam sim no |
6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A |
|
Tripping Curves |
B, C, D |
|
Rated Voltage |
230/400V AC |
|
Rated Zaus |
50/60 Hz |
|
Txhaum Muaj Peev Xwm |
6 kA (Standard series; mus txog 10 kA muaj rau siab -kev ua tau zoo series) |
|
Mounting Hom |
35 hli DIN Rail |
|
Terminal Hom |
Pillar - hom ntsia hlau davhlau ya nyob twg (Ntaus: mus txog 25 mm2) |
|
Khoom siv tsev |
Nplaim taws-cov thermoplastic retardant (PA66, Glow hlau kuaj 960 degree) |
|
Qhov taw qhia xwm txheej |
Qhov zoo ON/OFF hu rau txoj hauj lwm qhia |
|
Cov qauv siv tau |
IEC / EN 60898-1 / IEC / EN 60947-2 |
Tripping Curve Xaiv
Xaiv qhov tseeb tripping nkhaus tiv thaiv kev cuam tshuam tsis zoo thaum ua kom nrawm nrawm nrawm.
Curve:Tsim los rau cov kab hluav taws xob uas tsis tshua muaj hluav taws xob (3 - 5 Hauv). Qhov zoo tshaj plaws rau cov teeb pom kev hauv tsev, dav dav - lub hom phiaj qhov hluav taws xob, thiab cov khoom siv tiv thaiv.
Curve:Ua siab ntev me ntsis luv -ntev inrush tam sim no (5 - 10 Hauv). Kev xaiv tus qauv rau kev lag luam kev faib tawm, lub tshuab me me, twj tso kua mis, HVAC units, thiab cov khoom siv hluav taws xob dav dav.
Curve:Engineered rau hnyav- lub luag hauj lwm loads nrog siab sib nqus inrush tam sim no (10 - 20 Nyob rau hauv), xws li transformers, loj motors, thiab tshwj xeeb cov khoom siv.
Manufacturing & Quality Control
Batch-rau-batch sib xws yog nyob ntawm precision manufacturing es tsis yog generic los ua ke. Peb txoj hauv kev tsim khoom qhia txog kev ncaj ncees ntawm cov qauv:
Precision Plastic Moulding:Cov vaj tse insulating yog tsim los ntawm kev tswj kev txhaj tshuaj molding kom tswj tau qhov ntev ntawm qhov ntev, ua kom muaj kev sib raug zoo ntawm lub davhlau ya nyob twg, ruaj ntseg DIN-rail mounting, thiab zoo ib yam sab nrauv ntawm cov khoom siv ntau lawm.
Internal Component Coordination:Cov txheej txheem kev khiav hauj lwm, bimetallic thermal strip, electromagnetic coil, thiab arc -chute los ua ke yog calibrated los tswj cov kev khiav hauj lwm meej.
Factory Testing Protocol:Cov kab ntau lawm ua cov qauv kuaj xyuas suav nrog kev ua haujlwm txhua yam, kev txuas hluav taws xob txuas ntxiv, dielectric tiv taus (kev ua haujlwm rwb thaiv tsev txog li 2.5 kV), thiab kev mus ncig -cov pov thawj yam ntxwv raws li cov qauv IEC.
Daim Ntawv Thov Scope
Chaw nyob:Ceg - tiv thaiv Circuit Court nyob rau hauv cov neeg siv khoom, teeb pom kev zoo circuits, thiab kev faib khoom hauv tsev.
Kev lag luam:Cov tsev ua haujlwm, cov chaw muag khoom, thiab cov HVAC cov rooj sib tham me me uas yuav tsum tau muaj ob-kev cais tus ncej.
Lub teeb Industrial:Control panels, auxiliary machinery, thiab me me motor tis circuits. (Daim ntawv thov lub cev muaj zog yuav tsum tau txheeb xyuas qhov pib tam sim no tiv thaiv qhov kev xaiv mus txawv tebchaws).
OEM, ODM & Lag luam wholesale Customization
Txhawm rau txhawb kev faib khoom lag luam thiab cov neeg tsim vaj huam sib luag, peb muab cov kev xaiv tsim khoom tsim tau:
Laser Printing & Branding:Kev cai logo, tus qauv naj npawb, thiab laser - kos cov kab kos rau ntawm lub tsev.
Labeling & Ntim:Customized khw muag khoom lub thawv (cov thawv sab hauv ntawm 6 pcs rau 2P), pawg master cartons, barcodes, thiab export thawv cim.
Hluav taws xob Configuration:Kev ntsuas ntsuas tam sim no, kev muaj peev xwm tawg, thiab kev ntsuas tshwj xeeb yog qhov tsim nyog.
Quotation Request Guide
Txhawm rau kom tau txais cov lus hais meej thiab sai, thov muab cov txheej txheem hauv qab no:
|
Ncej Configuration |
2P |
|
Rated Tam sim no |
(E.g., 16A, 32A) |
|
Tripping Curve |
(B, C, lossis D) |
|
Txhaum Muaj Peev Xwm |
(piv txwv li, 6 kA) |
|
Siv tau Standard |
(IEC 60898-1) |
|
Ntim & Ntim |
(Standard bulk lossis kev cai ntiag tug -label ntim) |
|
Lub Hom Phiaj Lag Luam / Qhov Chaw |
(Rau kev pov thawj ua raws) |
Cov lus nug nquag
Q: Ob chav -Pole Miniature Circuit Breaker yog dab tsi?
A: Ob chav -Pole Miniature Circuit Breaker, feem ntau hu ua 2P MCB, yog ib qho khoom siv tiv thaiv hluav taws xob nrog ob tug ncej. Nws yog tsim los tiv thaiv qhov sib thooj ntawm Circuit Court tiv thaiv overload thiab luv luv -circuit tej yam kev mob thiab tso cai rau cov cuam tshuam tus ncej raug txiav ua ke.
Q: Qhov txawv ntawm 1P thiab 2P MCB yog dab tsi?
A: 1P MCB tiv thaiv ib tus ncej, thaum 2P MCB suav nrog ob tus ncej hauv ib lub cuab yeej.
Kev teeb tsa 2P raug xaiv thaum tsim hluav taws xob tsim hluav taws xob xav tau ob-ncej tiv thaiv lossis kev sib cais ib txhij ntawm cov khoom sib txuas.
Q: "2P" txhais li cas ntawm MCB?
A: "2P" txhais tau tias ob tug ncej.
Nws piav qhia txog kev teeb tsa tus ncej ntawm lub breaker thiab yuav tsum tsis txhob tsis meej pem nrog cov ntsuas tam sim no lossis lub peev xwm tawg.
Q: Qhov txawv ntawm B, C thiab D nkhaus MCBs yog dab tsi?
A: Peb qhov nkhaus muaj qhov sib txawv tam sim no sib nqus mus txawv tebchaws.
Curve feem ntau yog xaiv rau circuits nrog qis inrush tam sim no.
Curve feem ntau yog siv rau kev lag luam dav dav thiab kev lag luam loads nrog nruab nrab pib tam sim no.
Curve yog npaj rau cov ntawv thov nrog kev pib siab dua lossis inrush tam sim no.
Q: Puas yog 2P MCB haum rau kev tiv thaiv lub cev muaj zog?
A: Nws tuaj yeem siv rau kev tiv thaiv hluav taws xob hauv qee qhov kev siv lub cev muaj zog, tab sis MCB yuav tsum tsis txhob raug kho raws li lub cev muaj zog ua tiav - tiv thaiv kev daws teeb meem. Daim ntawv thov lub cev muaj zog xav tau kev xav txog kev pib tam sim no, kev xav tau ntau dhau, cov khoom siv tiv thaiv lub cev muaj zog, thiab cov qauv hluav taws xob siv tau.
